If your Ionic Breeze shows the red light that indicates it needs cleaning, you might have to take the entire unit apart to get it to work. I did that and found the two brass contacts inside the bottom of the unit were extremely dirty. Cleaned those and put everything back together and it works fine. It was a tedious job but it got the unit working. Here's a link that could help you restore your unit. Zony Jones, take a look on here and see if this looks like yours. I am not sure, but I would think that there is a fuse on the circuit board somewhere. This is a bit of a beast in getting any information, but I am certain we'll get it done. Post a few images once you have it apart :-). Hope this helps, good luck. I had the same problem and was able to get my Ionic Breeze working by removing the faulty on off switch. When depressed, my switch cycles through the modes Hi, Med, Low, and Off. Two blue wires run from my swith to other circuitry also located in the top portion of the unit.

I cut and stripped the wires and tested the switch expecting to get continuity each time the switch was pressed. Of course, nothing happened. I then touched the two blue wires running to the circuitry mentioned above and the unit immediately turned on.Diy Composting Toilet Rv Right now i just have the two blue wires, that require shorting, hanging on the outside of the unit and not touching. Price Pfister Kitchen Sink Soap DispenserTo change modes I just touch the wires for a moment, then let hang again. Property For Sale In Elko BcI'll either replace the switch with another Ionic Breeze switch, or will buy a switch with similar functionality and figure out a way to mount. I just love the smell of my Ionic Breeze. Haters can bad mouth these units all they want but when I had bed bugs, they dissappeared when the unit was on and my health has never suffered while my unit(s) were operational.

I tried the fixes described here (thank you for posting them) but that not what was wrong with mine. My symptoms were that the unit did nothing - acted completely dead, no lights of any kind and pushing the button did nothing at all. Like others mentioned, I checked around for fuses but none in this model at least. After I tried to see if the switch was bad as some others reported (mine tested fine), I noticed something else nearby. Underneath the switch there is a small partially- sort of semicircular circuit board (that is basically the bottom of the switch). Upon looking closely at mine, I noticed what looked like corrosion. You know, when copper turns bluish-green on pipes and such kind of corrosion? Well sure enough, one of the copper circuit traces on the back of this little circuit board had become corroded and had corroded all the way through. I checked it with a multimeter first - open circuit. Then carefully scraped away the crud with a pocket knife to confirm that the copper had been eaten away for whatever reason.

Normally the copper traces are covered by some kind of greenish protective film on this and other circuit boards, but apparently it gave way. Had moisture leaked in around switch area? Once I found this, the fix was easy - I just soldered a little 1 inch piece of wire to bypass the corroded trace on the circuit board - this is low voltage, so most any wire will do. Just be careful to not overheat the board when soldering, and not touch any of the other traces on the circuit board. After this, viola - works perfectly once again. Hope this is helpful to someone else like me to keep their breeze flowing a little longer...while I had it apart, cleaned thoroughly as others have suggested. One if the thin wires on my quadra snapped. Any ideas in how to repair or replace this wire? Where's the fuse at Unit does not work. Ordered a new lamp from Amazon & it has been thoroughly cleaned but still does not do anything.Air Purifier Repair An air purifier helps rid your home of dirt, dust, pet hair, and other pollutants.

This Fix-It Guide on air purifier repair tells how an air purifier works, what often goes wrong, how to identify an air purifier problem, and what parts and tools you will need to fix it. It then gives simple step-by-step instructions for how to disassemble a mechanical air purifier, how to clean a foam filter, how to replace ionizer wires, and how to test an air purifier precipitating cell. This guide also refers to electrical cord repair, motor repair, appliance controls repair, and fan repair for more specific repairs.How Does an Air Purifier Work?An air purifier is a small appliance designed to filter airborne pollutants from indoor spaces. Although dust is most noticeable where it settles and collects, the average home has about three million dust particles suspended in every cubic foot of air. There are two types of air purifiers: the mechanical type and the electronic type. Both come in small-room and whole-house models. In a typical mechanical air purifier, a blade fan or a squirrel-cage fan draws air through a series of filters, including a prefilter (to remove the largest particles), one or more activated carbon or charcoal filters (to remove smaller odor-causing particles), and maybe a type of HEPA ( high- efficiency particulate- arresting) filter.

Some mechanical units include an ion generator to charge remaining dirt particles, causing them to adhere to room surfaces.The most effective kind of air purifier uses an electrostatic precipitator to remove very fine particles, such as cigarette smoke and pollen, from the air in a room. The precipitator gives air particles a positive charge and then traps them with a negatively charged grid. The purifier also may contain filters to remove dust and odors, as well as an ionizer to add negative ions to the clean air. The ionizer supplies a strong negative charge to one or more parts called needles. An intense electric field is developed at the point of a needle, and it creates ions in the atoms in the air. Positive ions are attracted to the needle, while negative ions flow outward. Don’t worry, there won’t be a quiz.What Can Go Wrong with an Air Purifier?Lots of things can go wrong with air purifiers. Fortunately, most of them are common problems that you can easily fix. The electrical cord may fail, the motor may fail, the switch may be faulty, the fan may be loose, or the motor shaft may be frozen.

In addition, the precipitating cell may become dirty, motor bearings may be dry, filters and air intakes may be clogged or dirty, collector plates may be bent, and ionizer wires may be broken. You probably can fix any of these problems yourself.Do not operate an electronic air purifier or a mechanical purifier with ionizer needles in a room with oxygen equipment or where combustible gases are present. Also, handle a precipitating cell carefully; it contains sharp metal edges and delicate parts.How Can I Identify an Air Purifier Problem?The first step in solving a problem is defining it.If the unit does not run or runs sluggishly, make sure power is on at the outlet and test and replace the electrical cord if faulty. Test the motor and replace or service if needed. Make sure filters are installed according to manufacturer’s directions. Inspect and service the switch as suggested in the Appliance Controls Fix-It Guide. Check for a broken fan hub or loose setscrew on the fan (either one would allow the fan blades to spin freely on the motor shaft);

replace a fan with a broken hub and tighten the setscrew. Try to turn the fan blades by hand; if the motor shaft sticks, lubricate the motor bearings.If an electronic air purifier hisses, crackles, or pops excessively, remove and clean the cell following the manufacturer’s directions.If the unit is noisy in other ways, lubricate the motor bearings, tighten the fan on the motor shaft, and remove any obstructions that might be hitting the blades.If the air purifier fails to clean air, first check the owner’s manual for air purifier capacity and compare it with your room size; replace the purifier with a larger capacity unit if necessary. Check and clean or replace filters (below); position inlet and outflow sides of the unit away from obstructions like walls, drapes, and large furniture; vacuum dust and lint from filter covers and air passages; remove the precipitating cell (electronic filters only) and examine the plates; they should be flat and uniformly spaced; if necessary, have the plates repaired professionally or install a new cell.

Test a precipitating cell (electronic purifiers only) and replace it if necessary. Locate and replace broken ionizer wires (electronic purifiers only).If there is an ozone odor in the room (electronic purifiers only), look for a defective collector plate or ionizer wire. If the unit is new, however, a slight odor may be noticed for the first few weeks.Fix-It TipPlace an air purifier near the source of pollutants if possible. Position it so that cleaned air blows out toward the occupied parts of a room. It’s best to run an air purifier continuously to get the greatest benefit from it.What Do I Need for Air Purifier Repair?You can get replacement parts from the manufacturer or aftermarket supplier , as well as common parts at your local hardware store. In addition, you’ll need the following tools:ScrewdriversPliersMultimeterVacuum cleanerWhat Are the Steps to Air Purifier Repair?Disassemble a mechanical air purifier:Turn off the unit and unplug it. Press the release buttons to remove the intake grilles containing foam pre-filters;

then remove the filters.Remove any screws holding the filter housing in place. To access the fan, remove the long screws holding the main housing together, and separate the halves.Remove the fan by prying or twisting the locking ring from the end of the motor shaft; you probably should wear safety goggles for this step. Be careful not to bend the ring as you remove it.Remove the screws holding the switch and the motor housing together. Then pull the housing apart to expose the motor. The switch module will now slide out from the channels in the housing.Clean an air purifier foam filter:Remove the intake grill from the air purifier.Gently vacuum the filter through the grille.Replace air purifier ionizer wires:Unplug the air purifier and pull out the precipitating cell.Use needle-nose pliers to unhook the wire spring from the connector at each end of the cell; if necessary, depress the connector with a screwdriver to free the wire.Reverse the procedure to install the new wire.Test an air purifier precipitating cell:Remove the precipitating cell from the air purifier.
