With this ductless ac troubleshooting guide, you can find problems with your system, fix it yourself, and save a lot of money.We will guide you through the process of identifying the problem and repairing your air conditioner or heat pump.The normal service charge would cost you over $100 but, with this guide, you can save that money. **NOTE** Only you can assess your ability to perform these actions. This is a guide and cannot give the details/procedures for every possible situation. If your unit is not operating, you should begin your ductless ac troubleshooting by checking the display on the fan coil for a fault code. In most units, the display will show an E with a number. With that number you can narrow down the problem by referring to the user manual/installation instructions.Next, you should check the room temperature setting. On most units this is done with the remote control. Ensure that the unit is in the proper mode and the setpoint is correct. You should also make sure the unit has been off for at least three minutes.

If the display on the air handler is blank, check the fuse or breaker for the unit. In the case of a tripped breaker, you should check the wiring connections in the outside unit. Some units also have a fuse on the control board in the air handler. Continue your ductless ac troubleshooting by checking the air filter. It should be washed at least every month. Also check to see if there is any ice buildup on the coil. Digital Mavica CameraIf there is ice build up, check to make sure the fan is working. Blue Merle Sheltie Puppies For Sale In TexasMake sure the blower wheel is free to move. Pekingese Puppies For Sale In IowaIf it is free and the fan is not working then the problem is probably the motor or the control board.

If the fan is working, allow the ice to melt and check the refrigerant level in the unit. If there is no ice and the fan is working, you should go to the outdoor unit. If the fan on the outside unit is not running, you should check the dual run capacitor. Our capacitor testing guide will help you with that. If the capacitor can is bulging, it is a good indication that it is bad. If the capacitor is good the condenser fan motor may be bad. You can use our fan replacement guide to help you.If the fan is running, feel the compressor to see if it is running. If it is hot to the touch and not running, shut off the power and cool the compressor by pouring water over it. Then, check the outdoor coil and make sure it is clean. You should also check the dual run capacitor.After the unit is running, you should check the refrigerant level.If, after the compressor is cooled down, the unit makes a loud humming noise when it is trying to start, the compressor rotor may be stuck. You can use a hard start capacitor to try to get it to run.

If the compressor still does not start, it may need to be replaced. You can use our compressor testing guide to check to be sure.If the fan and compressor are running but the cooling or heating is insufficient, start by cleaning the unit. Ensure the fan coil, filter, and condenser coil are clean. Then you can check the refrigerant level and adjust per the operating instructions.**NOTE** IN SOME COUNTRIES, YOU MUST BE CERTIFIED BY THE GOVERNMENT TO HANDLE REFRIGERANT. If the unit's refrigerant charge is adequate, the unit may be improperly sized. The only way to tell if the unit is the proper size is through a process called a load calculation. If your unit is dripping water, you should begin your ductless ac troubleshooting by checking the drain hose to see if it is clogged. The easiest way to do this is with a bottle of water. Outside, stick the end of the hose in a bottle of water. Seal around the bottle opening with your hand. Then squeeze the water bottle and then pull the hose out.

The water should drain but this may need to be done a few times to make sure the line is clean.If the hose was not clogged, check to make sure the fan coil unit is sloped properly. The unit should be slightly out of level with the end attached to the drain hose slightly lower than the other end. If the remote does not work, you can replace the batteries. If it still does not work or you can't find it, most units have an emergency button on the fan coil unit that you can push to make it run. It will then operate as necessary to maintain a default temperature. You should complete your ductless ac troubleshooting by observing a complete heating or cooling cycle. Now, you can get live support or leave a message for the HVACrepairguy through Facebook Messenger. INSTRUCTION MANUAL Split System Air Conditioner Save These Instructions! OI-85264180330005 ©SANYO 2002 COOL/DRY Model KS0951 KS1251 KS1852 Printed on Recycled Paper... Features This air conditioner is equipped with cooling and drying functions.

Details on these functions are provided below; refer to these descriptions when using the air conditioner. Microprocessor Controlled Operation • The interior compartment of the remote control unit contains several features to facilitate automatic operation, each logically displayed for easy use. Page 3: Table Of Contents24 Operating Range ... 24 Product Information If you have problems or questions concerning your Air Conditioner, you will need the following information. Model and serial numbers are on the nameplate on the bottom of the cabinet. Page 4: Installation Location, Electrical Requirements, Safety Instructions Otherwise there is a risk of suffocation in an extreme case. CAUTION Do not turn the air conditioner on and off from the power mains • switch. Use the ON/OFF operation button. Page 5: Names Of Parts This illustration is based on the external appearance of a standard model. NOTE Consequently, the shape may differ from that of the air conditioner which you have selected.

This air conditioner consists of an indoor unit and an outdoor unit. Page 6: Unit Display And Operation Selector TIMER lamp This section picks up infrared signals from the remote control unit (transmitter). This position is for operating the air conditioner with the wireless remote control unit. Set the selector normally in this position. Switch the selector to the OFF position if you are not going to use the air conditioner for a few days or longer. Page 7: Remote Control Unit (display) Remote Control Unit (Display) Displayed when main unit sensor is in use (1) Operation mode MILD DRY... (2) Fan speed AUTO... (3) Temperature setting 60 — 86 °F When set to 82 °F temperature indication ... Page 8: Remote Control Unit Press the buttons (TEMP .) Press the ON/OFF operation button This button is for turning the air conditioner on and off. Timer and Present Time First, press the program button to select the mode you want. setting buttons Each time you press the “HH” button, the hours advance by one.

NOTE NOTE The remote control unit sends the temperature signal to the air conditioner regularly at five minute intervals. If the signal from the remote control unit stops for more than ten minutes due to the loss of the remote control unit or other trouble, the air conditioner will switch to the temperature sensor which is built into the indoor unit and control the room temperature. Page 10: Using The Remote Control Unit Remote Control Unit The remote control unit may be operated either from a non-fixed position or from a wall-mounted position. To ensure that the air conditioner operates Installation Position correctly, DO NOT install the remote control unit in the following places: DO NOT •... 2) When taking out the remote control unit, pull it from the holder. Point the transmitter on the remote control unit at the sensor on the • indoor unit when operating the remote control unit and the air conditioner. Do not place objects which may block the transmitted signals between •...

Page 12: Operation With The Remote Control Unit, Manual OperationPress the setting buttons as described below and change the settings as desired. To stop the air conditioner, press the ON/OFF operation button again. STEP 1 STEP 5 STEP 1 Press the MODE selector button and select the desired mode. Page 13: Adjusting The Fan Speed Fan Speed A. Automatic Simply set the FAN SPEED selector button to the A microcomputer in the air conditioner automatically controls the fan speed when the the difference between the room temperature and the set temperature is detected by the microcomputer which then automatically switches the fan speed to the most suitable level. Page 14: Night Setback Mode Operation with the Remote Control Unit (continued) 3. Night Setback Mode The Night Setback Mode is used for saving energy. Press the NIGHT SETBACK button while the air conditioner is operating. To cancel the night setback function, press the NIGHT SETBACK button again. Page 15: Special Remarks

Special Remarks ``DRY'' ( ) Operation How it works? • • • • Power failure during operation Clicking Sound Clicking sound is • heard from the air conditioner • Remote Control Unit IMPORTANT • KS1852 and CL1852 Combination OI-330-15EG Once the room temperature reaches the level that was set, the unit repeats the cycle of turning on and off automatically. Page 16: Setting The Timer 1. How to set the (Example) To set to 9:10 pm. present time 2. How to set the OFF time (Example) To stop the air conditioner at 11:30 pm. Operation 1. Press the Program button ( three times. Press the HH button until PM 9 is •... Setting the Timer (continued) (Example) To start operation at 7:10 am. 3. How to set the ON time 4. How to set a program (Example) To start operation at 7:10 am. and stop the air conditioner at for daily ON/OFF operation Present... Page 18: Setting The 1-hour Off Timer Setting the 1-Hour OFF Timer 1. 1-Hour OFF Timer This function causes the unit to operate for one hour and then stop, regardless of whether the unit is on or off when this button is pressed.

Setting procedure: Regardless of whether the unit is operating or stopped, press the 1 HR. TIMER button. Page 19: Adjusting The Airflow Direction Adjusting the Airflow Direction 1. Horizontal The horizontal airflow can be adjusted by moving the vertical vanes with your hands to the left or right. When the humidity is high, the vertical vanes should be in the front CAUTION position during the cooling or drying operation. If the vertical vanes are positioned all the way to the right or left, condensation may begin to form around the air vent and drip down. Page 20: Operation Without The Remote Control Unit, Care And Cleaning 1. When the air conditioner is not running If you want to turn on the air conditioner, switch the operation selector to the OFF position, and then to the ON position. The set temperature and fan speed are automatically set at the NOTE last selection before stopping. Care and Cleaning (continued) Anti-mold filter The anti-mold filter behind the air intake grille should be checked and cleaned at least once every two weeks.

How to remove the 1. Grasp both ends of the anti-mold filter 2. Push the anti-mold Cleaning Use a vacuum cleaner to remove light dust. KS0951/KS1251 NOTE The air cleaning filter is not provided with the air conditioner and must be purchased separately. The first time that you buy the air clean filter, it is necessary to get the STK-ARF4B model with frame. When changing the filter subsequently, it is only necessary to replace the filter itself (model STK-F4B). Page 23: Tips For Energy Saving Care and Cleaning (continued) Removing and remounting • the air intake grille When using a footstool or the like, be careful not to let it tip over. CAUTION Washing the grille with • water • Tips for Energy Saving Do not •... Page 24: Troubleshooting, Operating Range Troubleshooting If your air conditioner does not work properly, first check the following points before requesting service. If it still does not work properly, contact your dealer or service center. Trouble Air conditioner does not 1.
